Diaphragm pressure gauges are used when medium is high viscous, crystallizing or with particles. DS500 series is particularly used in food, beverage, biochemical and pharmaceutical industry. The features are easy to open, cleaning without residues and quickly measuring point.
|
Applicable instrument |
Analog pressure gauge ; Digital pressure gauge ; Pressure transmitter |
|
Process connection Tri-Clamp |
Diaphragm housing material: SS304 ; SS316 ; SS316L Tri-clamp — 1½” ; 2” ; 2½” |
|
Diaphragm |
SS316L |
|
Temperature limited |
Standard -20℃ to +80℃ ; Option -40℃ to +200℃ |
|
Filling Fluid |
Glycerin for -20℃ to +80℃ ; Silicon oil for -40℃ to +200℃ |
|
Pressure ranges (for pressure gauge) |
Tri-clamp 1½” — 0/6 ~ 0/40 kg/cm2 (bar) Tri-clamp 2” — 0/1 ~ 0/40 kg/cm2 (bar) Tri-clamp 2½” — 0/1 ~ 0/16 kg/cm2 (bar) |
|
Accessory assembly (option) |
Clamp ring (ferrule) + welding socket ＜whole set type＞ Capillary for remote measuring (specify length of capillary when ordering) |
